Place of Origin:
China
Brand Name:
used for volvo
Certification:
Iso9001 CE
Model Number:
ANY
Product Description:
By installing quick coupler to your excavator, you can turn it into a tasking, functional piece of machinery. It makes the switching much easier among excavator attachments increasing the machine productivity and efficiency greatly. A series hydraulic quick hitch coupler is compatible with various brand of excavators.
Technical Data:
| Parameter | JT-mini | JT-02 | JT-04 | JT-06 | JT-08 | JT-08S | JT-10 | JT-17 | JT-20 |
| Carrier (ton) | 1-4 | 4-6 | 6-8 | 12-16 | 18-25 | 25-26 | 26-30 | 30-40 | 40-90 |
| Overall Length(C)(mm) | 300-450 | 520-542 | 581-610 | 760 | 920-955 | 950-1000 | 965-1100 | 1005-1150 | 1250-1400 |
| Overall Width(B(mm) | 150-250 | 260-266 | 265-283 | 351-454 | 450-483 | 445-493 | 543-572 | 602-666 | 650-760 |
| Overall Heigth(G)(mm) | 225-270 | 312 | 318 | 400 | 512 | 512-540 | 585 | 560-615 | 685-780 |
| Forearm Width(A)(mm) | 82-180 | 155-172 | 181-205 | 230-317 | 290-345 | 300-350 | 345-425 | 380-480 | 420-520 |
| Pins Distance(D)(mm) | 95-220 | 220-275 | 290-350 | 350-400 | 430-480 | 450-505 | 485-530 | 520-630 | 620-750 |
| Pins Diameter(mm) | 20-45 | 40-45 | 45-55 | 50-70 | 70-90 | 90 | 90-100 | 100-110 | 100-140 |
| Pins Height(mm) | 170-190 | 200-210 | 205-220 | 240-255 | 420-510 | 450-530 | 460-560 | 500-650 | 400-500 |
| Weight(kg) | 30-40 | 50-75 | 80-110 | 170-210 | 350-390 | 370-410 | 410-520 | 550-750 | 700-1000 |
| Hydraulic Kit | including tube, pins, solenoid valve, switch, bolts and nuts full set ready | ||||||||
Hydraulic Quick Coupler Main Features:
1.12 months warranty after receiving the machine;
2. Q345B materials with Korea made solenoid valve;
3. German made oil seals and joints;
4. Japan made switch.
5. All spare parts ready for installation ( pins, pipes, solenoid valve, switch, manual, kit, etc.)
